Features:

Steel frame provides strength and quiet operation

“T-Handle” release is easily accessible from front of operator

Operator re-connects automatically when handle is released

Adjustable partial open limit

Direct driven limit nuts for precise gate control

Auto-close timer 1-30 seconds

Ports for plug-in open and reverse loop detectors – DKS detectors only

Selectable loop/reverse input function; stop or reverse

Anti-tailgating feature helps to control un-authorized traffic

Standard normally closed stop circuit

Gate Tracker reporting output provides operator data to DKS access control system

Convenience outlets for accessory transformers

Built-in power switch and alarm reset switch

Simple bi-parting gate interface

Specifications:

Maximum gate width 35-ft.

Maximum gate weight 1000 pounds* (1/2 HP) or 1500 pounds* (1 HP). (*Assumes gate is on level ground, in good condition with properly adjusted hardware. Other external factors may affect the performance of the gate operator.)

1/2 or 1 HP continuous-duty motor

115, 230*, 208*, 460* VAC. (*230, 208, and 460 volt units use a step-down power transformer to achieve 115 volt operating voltage.)

Class I, II, III and IV applications

Compliant with UL 325 and 991, ETL Listed. (Note: To be compliant with UL 325 and industry safety guidelines, additional Type B1 and/or Type B2 entrapment protection devices are required to be installed with this gate operator. Your professional DKS system installer can provide you with more details on these devices and on current industry safety standards.)

Dimensions: 18.375"W x 31.675"H x 23.25"D

Options:

Plug-in loop detectors.

Heater kit for cold environments.

Secondary entrapment prevention devices.

Bi‐parting gate connection cable.

Gate operator control stations

Postal and Fire Dept lock boxes

Surge suppressors, time clocks, traffic signal.
